Optional Chrome Fininsh
Motor: 1/4 h.p., grease packed ball bearing, air-cooled, 110/60/1
- 6amps (50Hz available) Controls:
The following controls are standard on all Spar Mixers: Digital
Timer with tones, separate start and emergency stop buttons
so operators can shut down the mixer immediately in an emergency
situation, and thermal overload protection. Includes Cord
and Plug: 6 ft. flexible three wire cord and ground
prong. Transmission:
Heat-treated, hardened alloy, precision milled gears operate
with planetary action. Gears are packed in a long-lasting,
high pressure grease. Planetary gears are driven by direct
linkage to the motor drive shaft. This design yields high-torque
mixing power and less energy consumption than non-direct drives. Speeds:
(Agitator rpm)
1. Low Speed 132
2. Intermediate Speed 284
3. High Speed 590 Bowls and Agitators: Standard
equipment includes a 8Qt. (7.6L) 304 series stainless steel
bowl, dough hook, flat beater, and whip. A sturdy hand lever
on the body column raises and lowers the bowl as well as locking
in place at the top and bottom positions. Additional Features:
Easy to clean base. Finish: Top (transmission cover): metallic bronze epoxy enamel
Bottom: metallic gray epoxy enamel Shipping Information:
N.W. 55lbs
(25kgs)
G.W. 60lbs
(27kgs)
Carton Size: Depth 18.4in.(47cm) Width 14.1in.(36cm) Height
25.8in.(66cm)
Cartons may be reinforced for shipping and weights and sized
may vary. Warranty: One year parts and labor, two
additional years on transmission parts.
